DC USB PD 3.0 charging adapters



SlimQ M0002 DC to PD3.0(DC5525, 2C2A) (Amazon.de) (Amazon.com) (SlimQ web site)

Key product benefits:
  • DC input 5V-24V using common 5.5x2.5mm jack.
  • 2 UsbC output PD3.0 (5-15V3A, 20V5A - 100W per each plug even with simultaneous use)
  • 2 UsbA output QC3.0 (5-9V/3A, 12V2.5A - 30W per each plug but when using both ports at the same time 15W+15W)
  • It is a buck-boost module, it can not only reduce voltage but also boost, for example from 12V to 20V, which is quite a useful and outstanding feature.
  • Soft silicon anti-shock heat-resistant bumper.
  • PD12V support. It's useful in case you want to replace the conventional AC-DC 12V adapter using the UsbC-DC cable.
  • PPS 21V support is important for some smartphones, such as the Google Pixel 9 Pro XL or Google Pixel 10 Pro XL (37W and 45W respectively), and can only be achieved if the charger supports the PPS 21V protocol.
  • Very low idle power consumption! - it's only 0.03Wh.
  • Weight: 79g
  • Dimensions(mm): 23x51x74 (with silicon bumper)
Product drawbacks:

  • DC 5.5x2.1mm jack is not compatible with the adapter's DC 5.5x2.5mm input.

Other product notes:
  • You can use any Laptop charger as a DC source with a 5.5x2.5 jack or with a 5.5x2.5 jack adapter.
  • Video-review of this device.​
Supported charging protocols claimed by manufacturer:

  • UsbC:

    • PD3.0, PPS, QC2.0-4.0, Apple, FCP, SCP, AFC, SFCP, PE

    • 100W, 5-15V3A, 20V5A

  • UsbA:

    • QC2.0-3.0, Apple2.4A, FCP, SCP, AFC, PE

    • 30W 5-9V/3A, 12V2.5A

Supported charging protocols detected by KM003C:

  • USB-C port (both ports):

    • PD3.0 100W, PPS, QC5 (Fixed 5V,9V,12V,15V-3A,20V-5A, PPS: 3.3-21V-3A)

    • FCP 18W (5.2V2A, 9V2A,12V1.5A)

    • SCP - not detected

    • AFC 18W (5V2A,9V2A)

    • QC2.0/3.0 (5V, 9V, 12V, 3.6-12V)

    • SFCP - not detected

    • MTK PE - not detected

    • BC1.2(DCP 5V1.5A)

    • APPLE 2.4A

  • USB-A port (both ports):

    • FCP 18W (5.2V2A, 9V2A,12V1.5A)

    • SCP 22W (3.3V-5.5V, 0.03A-5A)

    • AFC 18W (5V2A,9V2A,12V2A)

    • QC2.0/3.0 (5V, 9V, 12V, 3.6-12V)

    • MTK PE+1.1/2.0

    • BC1.2(DCP 5V1.5A)

    • APPLE 2.4A

SlimQ DC to USB PD3.0 Charging Hub
Amazon Basics USB 65W (1C)​

⇧ to the table of contents ⇧

XY-PDS100 DC/PD to USB(1C1A) (Amazon.de) (Amazon.com) (AliExpress)​

​Product key benefits:

  • Aluminium case which also helps cool down the device.

  • A screen that shows the output voltage and current.

  • Input DC12-28V 5.5x2.1mm jack (5.5x2.5 might not fit!) or UsbC (PD). UsbC and UsbA output (various fast charging protocols supported). According to the tests, the adapter was functional even with 6V DC input!.
  • It's recommended to use at least DC 21V input in order to get maximum PD20V5A (100W) output or PD 20V5A input.
  • PD12V support. It's useful in case you want to replace the conventional AC-DC 12V adapter using the UsbC-DC cable.

  • PPS 21V support is important for some smartphones, such as the Google Pixel 9 Pro XL or Google Pixel 10 Pro XL (37W and 45W respectively), and can only be achieved if the charger supports the PPS 21V protocol.

  • PPS 3.3-21V5A support, together with a cable rated for 5A (100W/240W), will provide the fastest possible Super Fast Charge 2.0 45W charging for Samsung S22, S23, S24 and S25 smartphones (Plus and Ultra versions).

  • You can connect to a USB PD adapter, which for example does not support PPS 21V or PD12V and get the charging protocols you need from this adapter.

  • Support for the very rare PD 5V5A mode! This sub-standard protocol is required for Raspberry PI 5

  • Relatively cheap device (11-15 USD on AliExpress)

  • Weight: 58g

  • Dimensions (mm): 21.2x46x54

Product drawbacks:

  • Only buck (step down) module. it can't make a higher voltage output than input voltage.

  • When both USB ports are used simultaneously, charging on both ports switches to using the basic DCP protocol at 5V.

Other product notes:

  • Idle power consumption 0.6W

  • You can use the car's 12V output as a DC source.
  • You can use any Laptop charger as a DC source with a 5.5x2.5 jack or with a 5.5x2.5 jack adapter.
Supported charging protocols claimed by manufacturer:

  • PD2.0 PD3.0 PPS

  • QC4+/QC3.0

  • Huawei SCP/FCP

  • VOOC/ Dash

  • Apple 2.4A.

  • Samsung AFC

  • VIVO 9V2A double motor.

  • PE+2.0

Supported charging protocols detected by KM003C:

  • USB-C port:

    • PD3.0 100W, PPS, QC5 (Fixed (5V,9V,12V,15V,20V)-5A, PPS: 3.3-21V-5A)

    • FCP 24W (5V2A, 9V2A,12V2A)

    • SCP 25W (3.4V-5.5V, 0.5A-5A)

    • AFC 24W (5V2A,9V2A,12V2A)

    • QC2.0/3.0 (5V, 9V, 12V,20V, 3.6-20V)

    • SFCP (5V, 9V, 12V)

    • MTK PE+1.1/2.0

    • BC1.2(DCP 5V1.5A)

    • SAMSUNG 5V2A

    • APPLE 2.4A

  • USB-A port:

    • FCP 24W (5V2A, 9V2A,12V2A)

    • SCP 25W (3.4V-5.5V, 0.5A-5A)

    • AFC 24W (5V2A,9V2A,12V2A)

    • QC2.0/3.0 (5V, 9V, 12V,20V, 3.6-20V)

    • SFCP (5V, 9V, 12V)

    • MTK PE+1.1/2.0

    • BC1.2(DCP 5V1.5A)

    • SAMSUNG 5V2A

    • APPLE 2.4A

    • VOOC

XY-PDS100 DC-DC USB PD adapter
XY-PDS100 DC-DC USB PD adapter
XY-PDS100 DC-DC USB PD adapter

⇧ to the table of contents ⇧

Anker Car Charger 3 ports (2C1A), 167.5W Max (Amazon.com)

Product key benefits:

  • 3 output ports 2 UsbC, 1 UsbA

  • Operation of all three ports is independent and the power supply is not changed when a new device is connected.

  • Supports 12V and 24V on-board vehicle power supply.

  • The voltage of the on-board network of a car does not affect the charging characteristics of the device.

  • The adapter is built on the principle of buck-boost ie can decrease or increase the output voltage depending on the request of the charged device.

  • Energy conversion efficiency - 90%.

  • PPS 5-11V5A support, together with a cable rated for 5A (100W/240W), will provide the fastest possible Super Fast Charge 2.0 45W charging for Samsung S22, S23 and S24 smartphones (Plus and Ultra versions).

  • The kit comes with a quality UsbC-UsbC cable 1m with support for 100W (20V5A) and USB3.2, resistance 120mOhm.

  • Load testing: 100W-30min:

    • Throttling detected after 10minutes

    • Maximum detected temperature 63°C

  • Load testing: 65W-30min:

    • Throttling was not detected, power was table.

    • Maximum detected temperature 57°C

  • Weight: 51grams​

  • Diameter (head):36mm, Length:81mm

Product drawbacks:

  • The adapter cannot provide 100W of power for longer than 10 minutes, but it can maintain 65W consistently.​​

Supported charging protocols claimed by manufacturer:

  • UsbC1:

    • PD3.0: 5V3A, 9V3A, 15V3A, 20V3A

  • ​UsbC2:

    • PD3.0: 5V3A, 9V3A

    • PPS (5-11V5A) - max 45W

  • UsbA:​

    • 5V3A, 9V2A, 10V2.25A (22.5W max)​​

Supported charging protocols detected by KM003C:

  • USB-C1 port:

    • PD3.0 100W, PPS, QC4+ (Fixed 5V,9V,15V-3A, 20V5A, PPS: 5-11V5A)

    • FCP 18W (5.2V2A, 9V2A)

    • SCP 22W (3.3V-10V, 0.03A-2.2A)

    • AFC 18W (5V2A,9V2A)

    • QC2.0/3.0 (5V, 9V, 12V, 3.6-12V)

    • BC1.2(DCP 5V1.5A)

    • APPLE 2.4A

  • USB-C2 port:

    • PD3.0 27W, PPS, QC4+ (Fixed 5V,9V-3A, PPS: 5-11V5A)

    • FCP 18W (5.2V2A, 9V2A)

    • SCP 22W (3.3V-10V, 0.03A-2.2A)

    • AFC 18W (5V2A,9V2A)

    • QC2.0/3.0 (5V, 9V, 3.6-9V)

    • BC1.2(DCP 5V1.5A)

    • APPLE 2.4A

  • USB-A port:

    • FCP 18W (5.2V2A, 9V2A)

    • SCP 22W (3.3V-10V, 0.03A-2.2A)

    • AFC 18W (5V2A,9V2A)

    • QC2.0/3.0 (5V, 9V, 3.6-9V)

Anker Car Charger 3 ports (2C1A), 167.5W Max
Anker Car Charger (2C1A), 167.5W Max
Anker car charger 167.5W heat

⇧ to the table of contents ⇧

Xiaomi 100W Car Charger (1C1A) (AliExpress) (Amazon.com) (Amazon.de)

Product key benefits:

  • 2 output ports 1 UsbC, 1 UsbA

  • Operation of all ports is independent and the power supply is not changed when a new device is connected.

  • Supports from 12V to 24V on-board vehicle power supply.

  • The voltage of the on-board network of a car does not affect the charging characteristics of the device.

  • The adapter is built on the principle of buck-boost ie can decrease or increase the output voltage depending on the request of the charged device.

  • Energy conversion efficiency based on tests - 87% (60W), 83% (80W).

  • Support for the PPS 5-21V5A protocol, together with a cable rated for 5A (100W/240W), will ensure the fastest possible charging for Samsung S22, S23, S24, S25 (Plus and Ultra versions) (45W), Google Pixel 9 Pro XL (37W), and Google 10 Pro XL (45W).

  • The set includes a high-quality 1m USB-C to USB-C cable with 100W (20V5A) and USB 2.0 support, 80mOhm resistance.

  • LED indication signaling that charger is powered.

  • Testing showed PD 3.0 support only up to 45W, higher power is only achieved with the PPS/Xiaomi Hypercharge protocol.

  • Load testing:

    • 100W (20V5A PPS):

      • under load, the power supply stopped.

      • Unable to ensure charging with 5A current at 18V and 16V

    •  80W (20V4A PPS)-11min:

      • Heating reached 80°C and throttling began with power limited to 40W. After cooling, operation resumed.​

    • 65W-30min:

      • Throttling was not detected, power was table.

      • Maximum detected temperature 70°C

  • Weight: 36grams​

  • Diameter (head):33.4mm, Length:74.8mm

Product drawbacks:

  • The adapter cannot provide 100W of power and operate at a current of 5A. 80W of power is provided for only 11 minutes, after which thermal protection and throttling are activated.

  • PD 3.0 is only available with a power output of up to 45W, but this is sufficient for the vast majority of smartphones on the market.

Supported charging protocols claimed by manufacturer:

  • UsbC1:

    • 20V5A

  • UsbA:​

    • 5V3A, 9V2A

Supported charging protocols detected by KM003C:

  • UsbC1 port:

    • PD3.0 45W, PPS (+Xiaomi) (Fixed 5V,9V,12,15V-3A,20V2.25A, PPS: 5-11V5A, PPS 5-21V5A)

    • FCP 18W (5.2V2A, 9V1.67A)

    • SCP 30W (3.6V-12V, 0.5A-2.5A)

    • AFC 24W (5V2A, 9V2A, 12V2A)

    • QC2.0/3.0 (5V, 9V, 12V, 3.6-20V)

    • DCP 5V1.5A

  • UsbA port:

    • FCP 18W (5.2V2A, 9V2A)

    • AFC 18W (5V2A, 9V2A)

    • QC2.0 (5V, 9V, 12V)

    • APPLE 2.4A

Xiaomi 100W car charger
Xiaomi 100W car charger
Xiaomi 100W car charger
Xiaomi 100W car charger kit cable

⇧ to the table of contents ⇧

USB 3.1 QC (Quick Charge) to PD (Power Delivery) converter/adapter (AliExpress)

Product key benefits:

  • USB 3.1, 10Gbps bandwidth

  • Converting UsbA port to UsbC port for charging or data transmission.

Product drawbacks:

  • Based on actual measurements, the charging modes in terms of power and voltage differ slightly from the product specifications.

Supported charging protocols claimed by manufacturer:

  • QC input: 5V3A/9V2A/12V1.5A/20V1.6A

  • PD output: 5V3A/9V2A/12V1.5A/20V1.6A

Supported charging protocols detected by KM003C:

USB-C port:

  • DCP

  • MTK PE+1.1/2.0

  • PD3.0 18W, Fixed: 5V2A, 9V2A, 12V1.5A

USB3.1 QC to PD adapter

⇧ to the table of contents ⇧

PD 65W module (Amazon.de) (Amazon.com) (AliExpress)

Product key benefits:

  • ​Input voltage range: DC 8V-30V

  • This is a Buck module, it cannot increase voltage, i.e. if you connect a 12V DC source, the output voltage will also be limited to a maximum of 12V.

  • There are three versions of the module with DC inputs: 5.5x2.5, 5.5x2.1, and Standard with open contact pads +/-.

  • Acceptable heating level, possible operation without a heat sink - maximum temperature 70-75°C on the chip at full load for 30 minutes.

  • PD12V support. It's useful in case you want to replace the conventional AC-DC 12V adapter using the UsbC-DC cable.

  • PPS 21V support is important for some smartphones, such as the Google Pixel 9 Pro XL or Google Pixel 10 Pro XL (37W and 45W respectively), and can only be achieved if the charger supports the PPS 21V protocol.

  • PPS 3.3-21V3A support support will also enable the fastest Super Fast Charge 2.0 45W charging for Samsung S25 smartphone (Plus and Ultra versions).

  • A fairly inexpensive module, costing about $2.50 on AliExpress.

  • Weight: 6.4g (Standard version)

  • Dimensions: Standard: 32×20×10mm / With DC Port: 44×20×10mm

3D models suitable for this device:
Product drawbacks:

  • This is a Buck module, it cannot increase voltage. When powered by 12V (e.g., from a car battery), you will not be able to charge a laptop, and the power will be limited to 36W (12V3A).

Supported charging protocols claimed by manufacturer:

  • Max 65W (5V/3A, 9V/3A, 12V/3A, 20V/3.25A)

  • ​PD3.1 (PPS), QC3.0, SCP, FCP, AFC, Apple Fast Charge, MTK PE+1.1/2.0

Supported charging protocols detected by KM003C:

​24V input:

  • PD3.0 65W, PPS, QC5 (Fixed 5V,9V,12V,15V-3A, 20V3.25A, PPS: 3.3-16V3.25A, 3.3-21V3A)

  • AFC 18W (5V2A,9V2A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0 (5V, 9V, 12V, 20V, 3.6-20V)

  • MTK PE+

  • BC1.2(DCP 5V1.5A)

  • APPLE 2.4A

16-12V input:

  • PD3.0 36W, PPS, QC4+ (Fixed 5V,9V,12V-3A, PPS: 3.3-12V3.25A)

  • AFC 18W (5V2A,9V2A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0 (5V, 9V, 12V, 3.6-12V)

  • MTK PE+

  • BC1.2(DCP 5V1.5A)

  • APPLE 2.4A

DC to PD 65W buck module
DC to PD 65W buck module
DC to PD 65W buck module

⇧ to the table of contents ⇧

SW3518 buck modules (1C1A) (Amazon.de) (Amazon.com) (AliExpress)

Product key benefits:

  • Input voltage range: DC 6V-32V

  • This is a Buck module, it cannot increase voltage, i.e. if you connect a 12V DC source, the output voltage will also be limited to a maximum of 12V. (12V3A=36W).

  • There are three versions of the module: Single/Double/Quadro. These are the same module, only multiplied on a common board and having a common DC input. The double and quadro modules operate completely independently of each other.

  • Acceptable module heating, possible operation without a heat sink - maximum temperature 72°C on one of the chips and 66°C on the choke at a maximum load of 60W for 30 minutes.

  • PD12V support. It's useful in case you want to replace the conventional AC-DC 12V adapter using the UsbC-DC cable.

  • PPS 21V support is important for some smartphones, such as the Google Pixel 9 Pro XL or Google Pixel 10 Pro XL (37W and 45W respectively).

  • PPS 3.3-21V3A support support will also enable the fastest Super Fast Charge 2.0 45W charging for Samsung S25 smartphone (Plus and Ultra versions).

  • The measured efficiency of the module is about 94%, which allows it to remain within acceptable temperature limits without using a heat sink.

  • There is built-in protection against overvoltage.

  • It is a fairly inexpensive module, with the Single version costing around $3 on AliExpress.

  • There is also a version of the module with an SW3516 chip, which does not support the VOOC charging protocol, unlike the SW3518P which is installed in the tested module.

  • Weight: Single: 12g , Double: 28.4g

  • Dimensions: Single: 51×18×12.5mm, Double: 64x36x13mm

Product drawbacks:

  • This is a Buck module, it cannot increase voltage. When powered by 12V (e.g., from a car battery), you will not be able to charge a laptop, and the power will be limited to 36W (12V3A).

  • The double module version that I tested behaved unusually: PD100W support was detected when connecting a load (laptop), the PD100W protocol was established, but as the power consumption of the load increased, the protection was triggered after 2-3 seconds and the charge was interrupted. Limiting the power (with a cable) to 60W did not fix the problem. The same stability issue was observed with PD45W (15V3A), and only with PD36W (12V3A) did everything work as it should. At the same time, the single version of the module worked perfectly with PD60W (20V3A). There is a suspicion that the double version of the module which was used in this testing is defective.

  • Simultaneous operation of both ports (USB-A and USB-C) is not stable, despite the manufacturer's claim operability of 5V on both ports.

3D models suitable for this device:
Supported charging protocols claimed by manufacturer:

  • USB PD3.0(PPS), Qualcomm QC4+/QC3.0, Huawei SCP/FCP, Apple 2.4A, Samsung AFC, VIVO 9V2A, MediaTek PE2.0, OPPO VOOC support (only supported by 3518), OnePlus DASH support (only supported by 3518)

Supported charging protocols detected by KM003C:
UsbC port:

24V input:

  • PD3.0 60W, PPS (Fixed 5V,9V,12V,15V,20V3A, PPS: 3.3-21V3A)

  • AFC 24W (5V2A,9V2A,12V2A)

  • SCP 40W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0 (5V, 9V, 12V, 20V, 3.6-20V)

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

16V input:

  • PD3.0 45W, PPS (Fixed 5V,9V,12V,15V3A, PPS: 3.3-16V3A)

  • QC2.0/3.0 (5V, 9V, 12V, 3.6-12V)

  • Other protocols are the same as above

13-12V input:

  • PD3.0 36W, PPS, QC4+ (Fixed 5V,9V,12V-3A, PPS: 3.3-11V3A)

  • QC2.0/3.0 (5V, 9V, 12V, 3.6-12V)

  • Other protocols are the same as above

UsbA port:

24V input:

  • AFC 24W (5V2A,9V2A,12V2A)

  • SCP 40W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0 (5V, 9V, 12V, 20V, 3.6-20V)

  • MTK PE+, MTK PE+2.0

  • Samsung 2A

  • APPLE 2.4A

  • VOOC (4A)

  • DCP

16-12V input:

  • QC2.0/3.0 (5V, 9V, 12V, 3.6-12V)

  • Other protocols are the same as above

⇧ to the table of contents ⇧

SW3518P buck modules (1C1A) front
SW3518P buck modules (1C1A) back
SW3518P buck modules (1C1A)
SW3518P buck modules (1C1A) IR front
SW3518P buck modules (1C1A) IR back

SW2303 PL5501 module (1C) (Amazon.de) (Amazon.com) (AliExpress)

Product key benefits:

  • Input voltage range: DC 3V-24V

  • This is a Buck-Boost module that lowers or raises the input voltage to the target voltage. For example, you can connect a 12V power supply to the input and charge a laptop using the PD20V protocol, or vice versa, use a 21V power supply and charge USB devices with any available voltage from 5V and above.

  • In terms of module heating, it operates stably at a power of about 60W (up to 75°C), but when the power increases to a maximum of 90-100W, the MOSFETs (90-95°C) located around the choke (there are 4 of them, 2 are used for buck mode, and the other 2 for boost), as well as the fuse (green) - 110-120°C. If heating is normal for the fuse, it is recommended to install small heat sinks on the MOSFETs (or at least on the back side of the module) if the module is expected to be loaded for more than 60W for a long time.

  • PD 12V support. This is very useful if you want to replace a regular AC-DC12V adapter. To do this, you will need a USB-C to DC cable.

  • PPS 3.3-21V5A support - provides the maximum possible charging power for Samsung smartphones of any model, including Ultra and Plus versions, as well as Google Pixel 9 Pro XL and Google Pixel 10 Pro XL.

  • The DC 5.5x2.1mm input power port simplifies the connection of a power source, and there are also contact pads for direct power supply.

  • The module board has contacts for connecting active cooling (fan).

  • Weight:21g

  • Dimensions: 37.1×73.4×14.4mm

Product drawbacks:

  • Using the module to power high-power consumers > 60W (e.g., a laptop) requires the installation of heat sinks on the MOSFETs.

3D models suitable for this device:
Supported charging protocols claimed by manufacturer:

  • PD, QC, FCP, high and low voltage SCP, AFC, SFCP and PE

Supported charging protocols detected by KM003C:
UsbC port:

3-24V input:

  • PD3.0 100W, PPS (Fixed 5V,9V,12V,15V-3A,20V5A, PPS: 3.3-21V5A)

  • AFC 24W (5V2A,9V2A,12V2A)

  • SCP 25W (3.3V-5.5V, 0.03-5A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0 (5V, 9V, 12V, 3.6-20V)

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

SW2303 PL5501 buck-boost module (1C) front
SW2303 PL5501 buck-boost module (1C) back
SW2303 PL5501 buck-boost module (1C) IR front
SW2303 PL5501 buck-boost module (1C) IR back

⇧ to the table of contents ⇧

SW3538 140W Black module (1C1A) (Amazon.de) (Amazon.com) (AliExpress)

Product key benefits:

  • Input voltage range: DC 6V-30V

  • This is a buck (step-down) module that can only lower the voltage to the target value.

  • PD 12V support is implemented. This is very useful if you want to replace a regular AC-DC12V adapter. To do this, you will need a USB-C to DC cable.

  • PPS 21V5A support allows you to charge all Samsung models at maximum power, including Plus and Ultra versions (S22-S25), as well as Google Pixel 9 Pro XL or Google Pixel 10 Pro XL (37W and 45W, respectively).

  • The DC 5.5x2.1mm input power port simplifies connection to the power source.

  • The module has a red LED indicator for connection to the power source.

  • Impressive size heat sink on the back of the module.

  • Large size choke.

  • Support for SVOOC and VOOC protocols (confirmed by testing), as well as TFCP (from the SW3528 datasheet).

  • Weight: 29g

  • Dimensions: 32×67.5×17.6mm

Product drawbacks:

  • No PD3.1 support, and 140W is achieved by a non-standard version of the PD3.0 protocol (20V7A)

3D models suitable for this device:
Supported charging protocols claimed by manufacturer:

  • Supports full gear PPS3.3-21V 6.3A 133W

  • Support PD140W 20V7A@140W

  • Support QC5/QC4+/QC3+/QC2.0

  • ​Support AFC/FCP/High Voltage SCP/SFCP

Additional information about protocol support from the SW2303 chip datasheet:

  • Supports TFCP protocol; provides four power curves: 25 W / 33 W / 45 W / 65 W

  • Supports SFCP protocol; outputs 5 V / 9 V / 12 V.

  • Supports VOOC protocol. VOOC1.0 output support

Supported charging protocols detected by KM003C:
UsbC port:

>21V input:

  • PD3.0 140W, PPS (Fixed 5V,9V,12V,15V-3A,20V7A, PPS: 3.3-21V6.35A)

  • AFC 24W (5V2A, 9V2A, 12V2A)

  • SCP 22W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0+ (5V, 9V, 12V, 3.6-20V)

  • SVOOC, VOOC

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

17V input:

  • PD3.0 45W, PPS (Fixed 5V,9V,12V,15V-3A, PPS: 3.3-16V5A)

  • AFC 24W (5V2A, 9V2A, 12V2A)

  • SCP 22W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0+ (5V, 9V, 12V, 3.6-12V)

  • SVOOC, VOOC

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

14V input:

  • PD3.0 36W, PPS (Fixed 5V,9V,12V-3A, PPS: 3.3-11V5A)

  • AFC 24W (5V2A, 9V2A, 12V2A)

  • SCP 22W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0+ (5V, 9V, 12V, 3.6-12V)

  • SVOOC, VOOC

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

UsbA port:

>21V input:

  • AFC 24W (5V2A, 9V2A, 12V2A)

  • SCP 22W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0+ (5V, 9V, 12V, 3.6-20V)

  • SVOOC, VOOC

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

14-17V input:

  • AFC 24W (5V2A, 9V2A, 12V2A)

  • SCP 22W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0+ (5V, 9V, 12V, 3.6-12V)

  • SVOOC, VOOC

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

SW3538 140W Black module (1C1A) back
SW3538 140W Black module (1C1A) front

⇧ to the table of contents ⇧

SW3538 140W Blue module (1C1A) (AliExpress)

Product key benefits:

  • Input voltage range: DC 6V-30V

  • This is a buck (step-down) module that can only lower the voltage to the target value.

  • PD 12V support is implemented. This is very useful if you want to replace a regular AC-DC12V adapter. To do this, you will need a USB-C to DC cable.

  • PPS 21V5A support allows you to charge all Samsung models at maximum power, including Plus and Ultra versions (S22-S25), as well as Google Pixel 9 Pro XL or Google Pixel 10 Pro XL (37W and 45W, respectively).

  • The DC 5.5x2.1mm input power port simplifies connection to the power source.

  • The module has a red LED indicator for connection to the power source.

  • Impressive size heat sink on the back of the module.

  • Large size choke.

  • Support for SVOOC and VOOC protocols (confirmed by testing), as well as TFCP (from the SW3528 datasheet).

  • Weight: 14.2g

  • Dimensions: 27.2×50.4×11.3mm

Product drawbacks:

  • No PD3.1 support

  • There is no actual support for 140W despite the statement on the product page; only 100W 20V5A is available. Another module built on the same SW3538 chip supports non-standard PD3.0 140W 20V7A.

Supported charging protocols claimed by manufacturer:

  • Support PPS/PD3.0/PD2.0

  • Support QC5/QC4+/QC3+/QC3.0/QC2.0- Support AFC

  • Support FCP

  • Supports high and low voltage SCP - Supports PE2.0/PE1.1- Supports SFCP

  • Support TFCP - Support VoOc

  • PD/SCP/V00C supports MCU

Additional information about protocol support from the SW2303 chip datasheet:

  • Supports TFCP protocol; provides four power curves: 25 W / 33 W / 45 W / 65 W

  • Supports SFCP protocol; outputs 5 V / 9 V / 12 V.

  • Supports VOOC protocol. VOOC1.0 output support

Supported charging protocols detected by KM003C:
UsbC port:

>21V input:

  • PD3.0 100W, PPS (Fixed 5V,9V,12V,15V-3A,20V5A, PPS: 3.3-21V5A)

  • AFC 24W (5V2A, 9V2A, 12V2A)

  • SCP 22W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0+ (5V, 9V, 12V, 3.6-20V)

  • SVOOC, VOOC

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

17V input:

  • PD3.0 45W, PPS (Fixed 5V,9V,12V,15V-3A, PPS: 3.3-16V5A)

  • AFC 24W (5V2A, 9V2A, 12V2A)

  • SCP 22W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0+ (5V, 9V, 12V, 3.6-12V)

  • SVOOC, VOOC

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

14V input:

  • PD3.0 36W, PPS (Fixed 5V,9V,12V-3A, PPS: 3.3-11V5A)

  • AFC 24W (5V2A, 9V2A, 12V2A)

  • SCP 22W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0+ (5V, 9V, 12V, 3.6-12V)

  • SVOOC, VOOC

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

UsbA port:

>21V input:

  • AFC 24W (5V2A, 9V2A, 12V2A)

  • SCP 22W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0+ (5V, 9V, 12V, 3.6-20V)

  • SVOOC, VOOC

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

14-17V input:

  • AFC 24W (5V2A, 9V2A, 12V2A)

  • SCP 22W (3.3V-12V, 0.03-4A)

  • FCP 24W (5V2A, 9V2A, 12V2A)

  • QC2.0/3.0+ (5V, 9V, 12V, 3.6-12V)

  • SVOOC, VOOC

  • MTK PE+, MTK PE+2.0

  • SFCP

  • Samsung 2A

  • APPLE 2.4A

  • DCP

⇧ to the table of contents ⇧

SW3538 140W Blue module (1C1A) front
SW3538 140W Blue module (1C1A) back

Support TinkerVault
Some links on this page might be affiliate links. This means I may earn a small commission if you make a purchase through these links, at no extra cost to you.
I buy and test every product ourselves to provide honest, unbiased reviews — your support helps me keep this project alive and independent.

Thank you for being awesome!

bottom of page
